Sprocket Help / Chain Recommendations

Looking to drop -1 on my R1, what is the difference between:

520
530

?
__________________
2010 Yamaha R1
Leo Vince Unlimited Mid Night Slip On's
Two Brothers Stainless Steel Y-Pipe
ECU Flashed
BMC Air Filter
Shogun No-Cut Frame Sliders
https://twitter.com/drozek

Last edited by drozek; 10-12-2012 at 06:31 AM.
drozek is offline   Reply With Quote
Sponsored Links
Advertisement

Old 09-20-2012, 07:38 AM   #2
ebags
1290!

ebags's Avatar

Join Date: Oct 2009
Bikes: KTM SuperDuke 1290R
Location: Melb, Aust.
Posts: 8,633
520 is thinner and lighter.

Here's some reading.

http://www.sportrider.com/tech/146_0...ing/index.html

__________________
"Adding power makes you faster on the straights. Subtracting weight makes you faster everywhere."
Colin Chapman




PETROLSPICE ORIGINALS®


ebags is offline   Reply With Quote
Old 09-20-2012, 07:40 AM   #3
Doppler
I eat my R1

Doppler's Avatar

Join Date: Jul 2010
Bikes: 07 R1
Location: Terra Australis
Posts: 825
It is the pitch of the chain. In very simple terms its how chunky or big the chain is. A 520 chain is smaller and therefore lighter. Its a common conversion especially for track bikes as there is less mass which equates to less momentum in the drive train.

-1 from the front sprocket will give a far more noticable effect. More bottom end and roll on torque but small sacrifice in top end speed.

Heaps on here about it all if you search.



.....I type way too slow, lol.
Doppler is offline   Reply With Quote
Old 09-20-2012, 07:40 AM   #4
drozek
I eat my R1

drozek's Avatar

Join Date: Apr 2011
Bikes: 2010 White R1
Location: Downers Grove
Posts: 504
Quote:
Originally Posted by ebags View Post
520 is thinner and lighter.

Here's some reading.

http://www.sportrider.com/tech/146_0...ing/index.html

Fanks!
__________________
2010 Yamaha R1
Leo Vince Unlimited Mid Night Slip On's
Two Brothers Stainless Steel Y-Pipe
ECU Flashed
BMC Air Filter
Shogun No-Cut Frame Sliders
https://twitter.com/drozek
drozek is offline   Reply With Quote
Old 09-20-2012, 07:58 AM   #5
ebags
1290!

ebags's Avatar

Join Date: Oct 2009
Bikes: KTM SuperDuke 1290R
Location: Melb, Aust.
Posts: 8,633
Quote:
Originally Posted by drozek View Post
Fanks!
No worries dude. I'm running a 520 setup with -1/stock aluminium rear and its noticeable that's for sure. Better punch off the line and gets through the rev range quicker.. and very respectable crusing rpm on the freeways.
__________________
"Adding power makes you faster on the straights. Subtracting weight makes you faster everywhere."
Colin Chapman




PETROLSPICE ORIGINALS®


ebags is offline   Reply With Quote
Old 09-20-2012, 07:58 AM   #6
C3L1CA
I eat my R1

C3L1CA's Avatar

Join Date: Aug 2007
Bikes: 06 R1, 04 f4i (stunt), 99 vstar 1100, 03 sumo wr450
Location: Oakdale, MN
Posts: 238
How big of a weight savings are people usually seeing?

When I just put on my 520 kit I think I kept 2 more links but it weighed the same as my old beat up 530 chain. I thought it seemed kind of weird but maybe it was my crappy scale or something else.
C3L1CA is offline   Reply With Quote
Old 09-20-2012, 08:16 AM   #7
ebags
1290!

ebags's Avatar

Join Date: Oct 2009
Bikes: KTM SuperDuke 1290R
Location: Melb, Aust.
Posts: 8,633
From my 2004 OE 530 to a EK MVXZ 520 I lost 122g... not a lot bit its rotational mass so on another hand its quite large; DID's race chain will save more.

The biggest saving comes from the sprockets. I saved 500g/1 pound-ish switching from a 45t OE sprocket to a Renthal aluminium 45t. The front from OE to Renthal superlite -1 was around 120g.

I doubt you notice the weight of the chain or front sprocket but I sure as shit noticed the 1lb loss in the rear sprocket. Not sire what the ultra light steel rears weigh but there's good weight saving there's too if wear bothers you... I do stiff all millage each year so alu suits me.
__________________
"Adding power makes you faster on the straights. Subtracting weight makes you faster everywhere."
Colin Chapman




PETROLSPICE ORIGINALS®


ebags is offline   Reply With Quote
Old 09-20-2012, 04:34 PM   #8
drozek
I eat my R1

drozek's Avatar

Join Date: Apr 2011
Bikes: 2010 White R1
Location: Downers Grove
Posts: 504
Can I just change my front sprocket to t16 and leave the rear stock?


Sent from my iPad using MO Free
__________________
2010 Yamaha R1
Leo Vince Unlimited Mid Night Slip On's
Two Brothers Stainless Steel Y-Pipe
ECU Flashed
BMC Air Filter
Shogun No-Cut Frame Sliders
https://twitter.com/drozek
drozek is offline   Reply With Quote
Old 09-20-2012, 04:56 PM   #9
quick kurt
I RACE U LOSE

quick kurt's Avatar

Join Date: Oct 2011
Bikes: 2000 R1 SOLD & 2006 R1 50th Anniversary & 2012 R1 50th G.P. Anniversary#145
Location: Philly now Langhorne Pa.
Posts: 3,158
Yes you can, 520 or 530 is on the chain itself to let anyone knoww what size parts are needed. I don't see any type of flashed ecu in your sig. A flashed ecu will do wonders for your power,my '12 is unbelievably stronger flashed. More so than the hp #s show.
__________________
'06 50th GYT-R CarbonSlipons,Akra Y Graves stacks,blockoffs,covers BMCair Bazzaz Zafm Zfi mapsw Vortex w/520ERV3 Shogun sliders Vortex rearsets Renthal med.comp Ballistic12cell Stompgrip CRG levers Galfer SBK fr&rr rotors ProboltTi'12 50th WGP#145. Graves full Ti carbon ex,stacks,blockoffs BMCair Yosh case,oilfill,yokenut,axleblocks Renthal w/520ERV3 CRG RC2's Watsen's Shogun framesliders Renthal med.comp Ballistic8cell ProboltTi Lucky 13th R1-013Squadron Member
quick kurt is offline   Reply With Quote
Old 09-21-2012, 05:18 AM   #10
drozek
I eat my R1

drozek's Avatar

Join Date: Apr 2011
Bikes: 2010 White R1
Location: Downers Grove
Posts: 504
-You can have an odd number front and odd number rear 6:32 PM
-Or even front and even rear 6:33 PM
-Never odd front and even rear 6:33 PM
-And you always need an even number of chain links, no matter what 6:36 PM

Is this true?
__________________
2010 Yamaha R1
Leo Vince Unlimited Mid Night Slip On's
Two Brothers Stainless Steel Y-Pipe
ECU Flashed
BMC Air Filter
Shogun No-Cut Frame Sliders
https://twitter.com/drozek
drozek is offline   Reply With Quote
Old 09-21-2012, 05:24 AM   #11
quick kurt
I RACE U LOSE

quick kurt's Avatar

Join Date: Oct 2011
Bikes: 2000 R1 SOLD & 2006 R1 50th Anniversary & 2012 R1 50th G.P. Anniversary#145
Location: Philly now Langhorne Pa.
Posts: 3,158
Any size front or rear,doesn't matter. Chain is always even # of links.
__________________
'06 50th GYT-R CarbonSlipons,Akra Y Graves stacks,blockoffs,covers BMCair Bazzaz Zafm Zfi mapsw Vortex w/520ERV3 Shogun sliders Vortex rearsets Renthal med.comp Ballistic12cell Stompgrip CRG levers Galfer SBK fr&rr rotors ProboltTi'12 50th WGP#145. Graves full Ti carbon ex,stacks,blockoffs BMCair Yosh case,oilfill,yokenut,axleblocks Renthal w/520ERV3 CRG RC2's Watsen's Shogun framesliders Renthal med.comp Ballistic8cell ProboltTi Lucky 13th R1-013Squadron Member
quick kurt is offline   Reply With Quote
Old 09-21-2012, 05:30 AM   #12
z064life
R1 Forum Star

z064life's Avatar

Join Date: Feb 2011
Bikes: 2010 R1, 2009 Roadstar Silverado, 2005 GS500F (wife's SOLD), PW50 (with training wheels), 2008 R6 (Sold)
Location: Indianapolis, IN
Posts: 14,941
Quote:
Originally Posted by Doppler View Post
It is the pitch of the chain. .
Incorrect

The 5 is the pitch (same for 520 and 530)..the 20 or 30 is the width

Quote:
Originally Posted by Doppler View Post
In very simple terms its how chunky or big the chain is. A 520 chain is smaller and therefore lighter. Its a common conversion especially for track bikes as there is less mass which equates to less momentum in the drive train.

-1 from the front sprocket will give a far more noticable effect. More bottom end and roll on torque but small sacrifice in top end speed.

Heaps on here about it all if you search.



.....I type way too slow, lol.
This part is correct in that a 520 chain is thinner and therefore lighter
__________________
Hey Greenstreak, it's z064life lazy ass

Phantom Squadron XO - http://www.r1-forum.com/forums/forumdisplay.php?f=50
z064life is offline   Reply With Quote
Old 09-21-2012, 05:35 AM   #13
z064life
R1 Forum Star

z064life's Avatar

Join Date: Feb 2011
Bikes: 2010 R1, 2009 Roadstar Silverado, 2005 GS500F (wife's SOLD), PW50 (with training wheels), 2008 R6 (Sold)
Location: Indianapolis, IN
Posts: 14,941
Quote:
Originally Posted by drozek View Post
-You can have an odd number front and odd number rear 6:32 PM
-Or even front and even rear 6:33 PM
-Never odd front and even rear 6:33 PM
-And you always need an even number of chain links, no matter what 6:36 PM

Is this true?
No...chains end up being even # of links but the rest of that is horseshit. You can do odd #teeth in front or back and any combonation
__________________
Hey Greenstreak, it's z064life lazy ass

Phantom Squadron XO - http://www.r1-forum.com/forums/forumdisplay.php?f=50
z064life is offline   Reply With Quote
Old 09-21-2012, 04:37 PM   #14
txbitt
Hook'em Horns

txbitt's Avatar

Join Date: Jul 2006
Bikes: 2007 R1
Location: Texan in Louisville Ky.
Posts: 2,825
Oh and use nothing but WD-40, always!
__________________

Signature courtesy of Petrol Spice
txbitt is offline   Reply With Quote
Old 09-21-2012, 09:52 PM   #15
gsxcorey
MummyMan

gsxcorey's Avatar

Join Date: Dec 2003
Bikes: 1999 r1, 07 GSXR 1k
Location: Austin, TX y'all
Posts: 8,644
technically correct or not everyone still calls it the pitch...even the chain/sprocket manufacturers lol.
__________________
Corey

Check us out on Facebook too.
gsxcorey is offline   Reply With Quote
Old 10-12-2012, 06:31 AM   #16
drozek
I eat my R1

drozek's Avatar

Join Date: Apr 2011
Bikes: 2010 White R1
Location: Downers Grove
Posts: 504
so i got a -1 in front and +2 in the rear, what is a recommended chain to use? any have any suggestions
__________________
2010 Yamaha R1
Leo Vince Unlimited Mid Night Slip On's
Two Brothers Stainless Steel Y-Pipe
ECU Flashed
BMC Air Filter
Shogun No-Cut Frame Sliders
https://twitter.com/drozek
drozek is offline   Reply With Quote
Old 10-12-2012, 06:41 AM   #17
ErikTaylor
Don't be so picky. I wasn't!

ErikTaylor's Avatar

Join Date: Oct 2012
Bikes: 06 R1
Location: Largo, FL.
Posts: 123
Quote:
Originally Posted by drozek View Post
so i got a -1 in front and +2 in the rear, what is a recommended chain to use? any have any suggestions
You can use anything from oring to xring. Try to find something with 9,000 lb tensile strength, and most importantly don't mix the numbers up. As in if you have a 520 front, make sure your rear is 520, along with your chain. Don't put 520 sprockets with a 530 chain. I'd personally stay away from eBay chains unless they are from a reputable manufacturer.
__________________
Modifications:


Vortex Rear sets
Galfer Lines
Woodcraft Covers
Shorty Levers
Roth Smog Plates
Cox Radiator Guard
Scorpio i900
Smoked Tail Light
Flushies
0 Gravity Windshield
Hotbodies Rear Hugger
Driven Grips
Vortex Sliders
Graves Clutch Slider
Vortex Slider Spools
Pro-Tek BF Caps
BF Socks
ErikTaylor is offline   Reply With Quote
Old 10-12-2012, 07:01 AM   #18
drozek
I eat my R1

drozek's Avatar

Join Date: Apr 2011
Bikes: 2010 White R1
Location: Downers Grove
Posts: 504
Quote:
Originally Posted by ErikTaylor View Post
You can use anything from oring to xring. Try to find something with 9,000 lb tensile strength, and most importantly don't mix the numbers up. As in if you have a 520 front, make sure your rear is 520, along with your chain. Don't put 520 sprockets with a 530 chain. I'd personally stay away from eBay chains unless they are from a reputable manufacturer.
what about the chain link length?
__________________
2010 Yamaha R1
Leo Vince Unlimited Mid Night Slip On's
Two Brothers Stainless Steel Y-Pipe
ECU Flashed
BMC Air Filter
Shogun No-Cut Frame Sliders
https://twitter.com/drozek
drozek is offline   Reply With Quote
Old 10-12-2012, 07:08 AM   #19
ErikTaylor
Don't be so picky. I wasn't!

ErikTaylor's Avatar

Join Date: Oct 2012
Bikes: 06 R1
Location: Largo, FL.
Posts: 123
Well the stock chain length is 116 links.

So if you are doing just a -1 in the front the stock link length will work. However if you are increasing the rear I'd say find a chain with a 120. You won't need all 120 links, but in this case, it's better to have more than not enough. You can always trim the chain to the desired length. Just make sure you leave some room for adjustments to tighten the chain incase it stretches on you down the road.
__________________
Modifications:


Vortex Rear sets
Galfer Lines
Woodcraft Covers
Shorty Levers
Roth Smog Plates
Cox Radiator Guard
Scorpio i900
Smoked Tail Light
Flushies
0 Gravity Windshield
Hotbodies Rear Hugger
Driven Grips
Vortex Sliders
Graves Clutch Slider
Vortex Slider Spools
Pro-Tek BF Caps
BF Socks
ErikTaylor is offline   Reply With Quote
Old 10-12-2012, 09:13 PM   #20
Whitevenum
HP Addict

Whitevenum's Avatar

Join Date: Aug 2012
Bikes: 07 White/Carbon Fiber R1
Location: Brooklyn, NY
Posts: 27
Interesting. So if i get the driven 520 with -1 front and stock t45 the bike will have a better launch? What if i get the t47 rear, what effects will happen there?
Whitevenum is offline   Reply With Quote
Sponsored Links
Advertisement

Reply

Thread Tools
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off

Forum Jump

Powered by vBadvanced CMPS v3.2.2

All times are GMT -7. The time now is 03:15 PM.



Powered by vBulletin®
Copyright ©2000 - 2014, Jelsoft Enterprises Ltd.
Motorcycle News, Videos and Reviews
Honda Grom Forum Harley Davidson Forum Honda 600RR Kawasaki Forum Yamaha R6 Forum Yamaha FZ-09 Forum
1199 Panigale Forum Roadglide Forum Honda CBR1000 Forum Vulcan Forum Yamaha R1 Forum Yamaha R3 Forum
Ducati Monster Forum Harley Forums Honda CBR250R Forum ZX10R Forum Star Raider Forum Yamaha Viking Forum
Suzuki GSXR Forum V-Rod Forums Honda Shadow Forum Kawasaki Motorcycle Forum Star Warrior Forum KTM Duke 390 Forum
SV650 Forum BMW S1000RR Forum Honda Fury Forum Kawasaki Versys Forum Drag Racing Forum Ducati 899 Panigale Forum
Suzuki V-Strom BMW K1600 Triumph Forum Victory Forums Sportbikes BMW NineT Forum
Volusia Forum BMW F800 Forum Triumph 675 Forum MV Agusta Forum HD Street Forum Suzuki GW250 Forum
Yamaha Motorcycles Victory Gunner Forum Honda Vultus Forum HD LiveWire Forum
R1-Forum.com is an independent Yamaha enthusiast website. Content on R1-Forum.com is generated by its users and R1-Forum.com is not in any way affiliated with Yamaha Motor Corporation, U.S.A.
